    SEC Series 160kW
    The SEC160 is a compact, reliable, and cost-effective all-in-one charging solution, providing up to 160kW of power. Powered by SINEXCEL's in-house designed, ETL-certified 40kW module, it delivers peak performance of 160kW and is backward compatible with up to 60kW, ensuring versatile coverage for a wide range of scenarios.
    View manual
    Contact us
    ULTRA WIDE OUTPUT
    VOLTAGE & HIGH EFFICIENCY
    Equipped with Sinexcel in-house-designed 40kW power module
    Various Charging Scenarios
    Destination Charging Stations Fleet Charging Port Charging Highway Rest Areas
    Enhancing the EV Charging
    Experience for Users
  • High-Visibility Display

    A 15'' high-resolution touch screen clearly presents essential charging information, including charging status, charging current, and pricing details, eyc. The bright, high-contrast screen ensures excellent readability, allowing users to quickly access real-time data for a smooth and efficient charging experience.

  • Multiple Authorization and Payment Methods

    The EV charger supports multiple authorization and payment methods to prevent unauthorized use, while streamlining the management of authorization and payments. It is compatible with credit cards, QR cards, and RFID cards.

  • Americans with Disabilities Act (ADA) Compliant

    The SEC160 charger is designed to be accessible to all users, with a screen positioned 105cm from the ground to ensure ease to guarantee that everyone can comfortably interact with the charger.

    • Cable Management System
    Protecting Cables from Physical Damage
    Ease of use and labor savings of

    Compact, Reliable and Cost-effective
    Solution for Business
    Compact, Reliable and Cost-effective
    Solution for Business
    Designed to perform in extreme temperatures, this system maintains full power output even in challenging conditions, ranging from -30℃ to +50℃, ensuring reliable performance in diverse climates.
    Comprehensive
    Protection Functions
    The system includes a robust set of protection features to safeguard both the device and the users, such as: protection function: Over current, over voltage, under voltage, ground fault, over temperature, short-circuit, insulation monitor (lMD), surge protection(SPD)
    Operations and Maintenance
    (O&M) Solution
    The chargers can be integrated seamlessly with SINEXCEL's O&M platform, offering remote monitoring, diagnostics, repair, and OTA upgrades, ultimately reducing labor costs and enhancing operational efficiency.
    LED Light:
    Charging status indicated to users through the intuitive color-coded light
    User Authentication:
    Credit card, QR card, RFID card
    Connector Options:
    CCS1(up to 500A)/NACS(up to 400A)
    Supports two wiring configurations:
    L1+L2+L3+PE / L1+L2+L3+N+PE, with no need for grid modification costs.
    Modular Design:
    Equipped with up to 4 power modules, smart power upgrade with minimization of human resourses and time cost.
    Certification & Standards & Customer Care
    Certifications:
    cTUVus, energy star, OCA 1.6. CTEP, NTEP, FCC
    Standards:
    UL 2202:2022, UL 2231:2022, CSA C22.2 No.346:2022, ICES-002:2020
    Customer Care:
    · SINEXCEL expert team quick response
    · Rapid on-site service
    · Remote technical support
    · Spare parts management
    Technical specifications
    ELECTRICAL
    		 Connector optionCCS1;NACS
    Rated Input Current200A
    Input Voltage Range480(±10%) @ 60 Hz
    DC Output Voltage200-1000V
    Maximum output currentCCS1 up to 350A(500A boost)
    NACS up to 350A(400A boost)
    Network TypeL1+L2+L3+PE or L1+L2+L3+N+PE
    ProtectionOver-Current, Over-Voltage,Under-Voltage,
    Ground-Fault,Over-Temperature, Short-Circuit,
    Insulation Monitor (lMD), Surge Protection(SPD)
    Power Factor≥0.99
    THDI≤5%
    Peak Efficiency96%
    Short Circuit Current Rating35kA
    USER INTERFACE &
    COMMUNICATION
    		 ConnectivityWi-Fi/Ethernet/4G
    User AuthenticationCredit Card, QR Code , RFID Card
    ISO 15118 Plug 8 ChargeHardware 15118-Ready
    DIN 70121 Yes
    Interface15 "touch screen
    Accessible For Wheelc ADA hair UsersYes
    Communications ProtocolsOCPP 1.6J, OCPP 2.0 J(Can Be Upgraded Later)
    RFID ReaderRFID reader (lSO 14443 8 lSO 15693)
    Remote managementRemote access.diagnostics,software updates
    GENERAL
    CHARACTERISTICS
    		 Protection RatingsNEMA 3R /IK10
    Enclosure materialHot-dip galvanized sheet
    Operation Altitude≤6561ft(2000m)
    Operating Temperature-22~149°F(-30~65°C)(50°C/122°F derate)
    Storage Temperature-58~176°F(-50~80°C)
    Humidity5~95%(non-condensing)
    Noise Level≤80dB(Within 1 meter)
    Cable Length(exposed)5m(7m optional)
    Dimensions(H*W*D)74.80*33.46*22.83In.(1900*850*580mm)
    CERTIFICATIONS
    		 Standards & CertificationsUL 2202:2022
    UL 2231:2022
    CSA C22.2 No.346:2022
    FCC Part 15 Subpart B:2021
    ICES-002:2020
    Energy Star
    CTEP&NTEP
    OCA 1.6
