      • HOME ENERGY
      Single phase hybrid inverter Three phase hybrid inverter
      Sinexcel ISUNA Series
      Single phase hybrid inverter
    • 3-6kW
    • 2 MPPT
      • Single phase hybrid inverter is suitable for residential rooftop appliation to transform solar energy into power, compatible with most of storage batteries, enpower your home anytime.
      Features
      Max. 15 units
      High scalability
      98%
      Max. efficiency
      Ultra silence
      Natural cooling
      Smart load control
      Leakage current protection
      150%
      PV configuration
      110%
      output overload
      80-550V
      Wider MPPT voltage range
      APP+H5
      data visible smart data analysis
      Datasheet
    • Model Name
    • Isuna 3000S
    • Isuna 3600S
    • Isuna 4000S
    • Isuna 4600S
    • Isuna 5000S
    • Isuna 6000S
      • Off-grid Output
      Nominal Output Power3000W3600W4000W4600W5000W6000W
      Nominal Voltage220V/230V/240V
      Nominal Frequency50/60Hz
      Nominal Output Current13.6A16.4A18.2A20.8A22.7A27.2A
      Nominal Output THDu<2%
      On-grid Parameter
      Nominal Output Power3500W3600W4000W4600W5000W6000W
      Max. Input Current13.6A16.4A18.2A20.8A22.7A27.2A
      Nominal Grid Voltage220V
      Output Current from Grid16.4A22.7A22.7A27.2A27.2A27.2A
      Input Voltage Range184-264V
      Nominal Frequency45-65Hz
      PV Input
      Max. Input Power4500Wp6000Wp6000Wp7500Wp7500Wp9000Wp
      Starting Voltage95V
      Max. Input Voltage600V
      MPPT Operating Voltage Range80-550V
      Full Load MPPT Operating Voltage Range300-500V
      Number of MPPTs2
      Max. In put String Per MPPT1
      Nominal Input Voltage360V
      Max. Input Current13A/13A
      Battery Parameter
      Battery TypeLithium-ion
      Nominal Battery Voltage51.2V
      Battery Voltage Range42-58V
      Max. Charging Voltage≤60V
      Max. Continuous Discharging Current75A85A85A100A100A100A
      Efficiency
      Max. Efficiency97.50%97.50%97.80%97.80%98.00%98.00%
      European Efficiency97.20%97.20%97.30%97.30%97.50%97.50%
      Max. Battery Charging/ Discharging Efficiency95.20%
      General Data
      Size((L*W*H)500mm*470mm*180mm
      Weight21kg
      Noise<25dB(A)
      Operating Temperature Range-25C~+60
      Cooling MethodNatural cooling
      Ingress Protection GradeIP65
      DisplayLED/APP/WIFI/4G/Bluetoothu
      Communication PortRS485/CAN/DRED/DO/Parallel port
      ProtectionDC Switch. PV Insulation Resistance Detection. Residual Current Monitoring. Anti-islandlng Protectton. Reverse Polarity Protection(PV&Baitery) AC Short Circuit Protection, AC Overcurrent ProtectionAC Overvoltage Protection LEVEL lll；PV&Battery LEVEL II. Surge Protection. Lightning ProtectionTYPE II
      Certification
      CE_LVDIEC 62109-1, IEC 62109-2, EN 62109-1, EN 62109-2
      CE_EMCEN61000-6-1EN61000-6-2EN61000-6-3EN61000-6-4
      Grid VDE-AR-N 4105.VDE V 0126-1-1.C10-11.G99.CE O-21EN50549
      NRS 097-2-1,AS 4777.2,R25,UNE217001,UNE217002,NTS 2.1
